Machinery / Electronics 3D Optical Video Measuring Machine VMM

Brand Name : ZL

Model Number : ZL-1502A

Certification : ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : T/T, L/C, Western Union

Supply Ability : 100 set per month

Delivery Time : 5-7 days

Packaging Details : Machinery / Electronics 3D Optical Video Measuring Machine VMM is packaged within wooden case

Product name : Machinery / Electronics 3D Optical Video Measuring Machine VMM

Power : 220v

The camera : Color 1/3 CCD camera

Thing fang view : 0.7~1.1mm

Working distance : 108mm

Z axis lifting : 150mm

Warranty : 12 month

Key words : 3D VMM

Contact Now

Machinery / Electronics 3D Optical Video Measuring Machine VMM

Video Measurement Instrument 3D Optical Video Measuring Machine

Download Brief: ZL-1502 Video Measurement Machine (Automatic type)...

Equipment Summary: The 3D Optical Image Measuring System is applicable for two-coordinate measurement across various fields including machinery, electronics, instruments, plastics, and more.

Main Features

Instrument equipped with RS-232 interface for computer connectivity, using specialized M2D measuring software for graphics processing and output
Measurement aiming system includes color CCD camera, zoom objective, and cross-line generator
Digital measurement and data processing system composed of grating ruler and DC-3000 electrical box
Multiple data processing, display, input and output functions with practical workpiece adjustment capability

Technical Parameters

Parameter	Specification
Instrument Model	3D Optical Image Measuring System
Workbench	Metal: 510×290mm \| Glass: 360×160mm
Motion Stroke	300×200mm
Instrument Weight	200kg
Camera	Color 1/3 CCD Camera
Zoom Optical Lens Range	0.7-4.5x
Video Magnification	30-230×
Field of View	0.7-1.1mm
Working Distance	108mm
Z Axis Lifting	150mm
Display Resolution	1µm \| X.Y Coordinate measurement error ≤ (3+L/200)µm
Lighting	Surface and transmitted light sources with adjustable brightness
Power	220V (AC) 50Hz 30W
Measuring Software	Standard automatic measurement software with automatic edge detection, deburring, point, line, circle, arc, angle measurement and adjustment capabilities

Measurement Functions

Elements: Multi-point measurement of points, lines, arcs, circles, ellipses, angles, rectangles with automatic recognition
Element Construction: Center, midpoint, intersection, line, circle, and angle construction
Element Preset: Point, line, circle, arc
Graphics: Coordinate panning, workpiece positioning
Any axis positioning and coordinate reset
Graphics zoom, pan, print, selection, and deletion functions
Image adjustment for grayscale, saturation, contrast with BMP format saving
Multiple edge detection modes with automatic point capture and shape recognition
Image support for S-terminal input with 640×480mm image size

Software Features

Multi-point, line, arc, circle, ellipse measurement for improved accuracy
Coordinate shifting and positioning for enhanced measurement efficiency
Element combination function for simple graphical combination of points, lines, circles, distances, and angles
Macro instructions for batch measurement of similar workpieces
Measurement data export to AutoCAD DXF format for documentation
Data export to Excel for statistical analysis and control chart generation
Multi-language interface switching
User program recording, editing instructions, and teach-mode execution
