20KN Computer Control Three Point UTM Machine With Extensometer

Range of testing speed : 0.001～200mm/min ; 500mm/min (1000mm/min is option)

Model Number : ZL-8001A

Power : 0．4KW（depending on different demand of force, using different motor）

Units : Kg, N, LB, TON, can be exchanged.

Brand Name : Zhongli

Certification : CE,ISO

Place of Origin : China

MOQ : 1 set

Price : negotiation

Payment Terms : T/T,L/C,D/A,D/P,Western Union,MoneyGram

Supply Ability : 100 sets per month

Delivery Time : 10 days after order

Packaging Details : 20KN Computer Control ServoThree Point Testing Machine With Extensometer is packaged within wooden case.

Max load : 5KN,10KN,20KN

Measuring accuracy : Display the value ±1%/Display the value ±0.5%

Accuracy of displacement measurement : Tolerance: ±0.5％/ tolerance: ±0.2％

Machine weight : （about）250 Kg

Contact Now

\n
\n
20KN Computer Control Three Point UTM Machine With Extensometer
\n
Equipment Overview
\n
\n The ZL-8001 2T Computer Universal Testing Machine combines electronic technology with mechanical transmission to deliver precise load speed control and accurate force measurement. This advanced testing equipment features high precision and sensitivity for load and displacement measurement, supporting constant-velocity loading and displacement testing. Designed for ease of operation, it is particularly suitable for quality control in production environments and is ideal for testing both metallic and non-metallic materials with loads up to 2 tons.\n
\n
Compliance Standards
\n
\n GB/T16491-1996 electronic universal testing machine\n
\n
Technical Specifications
\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n
ParameterSpecification
ModelZL-8001 2T Computer Universal Testing Machine
Maximum Load5KN, 1 ton, 2 ton
Accuracy Grade1% / 0.5%
Effective Measuring Range0.2%~100% (1 grade) / 0.4%~100% (0.5 grade)
Measuring AccuracyDisplay value \u00b11% / Display value \u00b10.5%
Tester ResolutionMax load 1/200,000, constant resolution
Effective Testing Width390mm (customizable)
Effective Tensile Stroke800mm, 1000mm, 1200mm (customizable)
Testing Speed Range0.001~200mm/min; 500mm/min (1000mm/min optional)
Displacement Measurement AccuracyTolerance: \u00b10.5% / Tolerance: \u00b10.2%
Power Systemhigh-performance AC Servo Motor + Driver + high-precision ball screw
Power Supply220V, 50HZ, 0.4kw
Machine Weight250kg
\n
Key Features
\n
    \n
  • Electronic limit protection for enhanced safety
    • \n
  • Fast/slow two-speed control for testing platform movement
    • \n
  • Manual or automatic return to initial position
    • \n
  • Overload protection (10% automatic protection)
    • \n
  • Multiple unit conversion: Kg, N, LB, TON
    • \n
  • Comprehensive fixture set included
    • \n
\n
Applications
\n
\n This universal testing machine performs static load testing including tension, compression, bending, shear, tearing, and peeling tests. It is suitable for testing various materials including plastic sheets, pipes, profiled materials, plastic films, rubber, wire and cable, steel, and glass fiber. Essential for material testing, research, and quality control applications.\n
\n\n Download Technical Brief\n \n20KN Computer Control Three Point UTM Machine With Extensometer\n
