5KN Single Column Microcomputer Control Material Testing Machine
Equipment Overview
The ZL-8003A Microcomputer Economic Material Testing Machine combines electronic technology with mechanical transmission, featuring accurate load speed, comprehensive force measurement range, and high precision for load, displacement measurement, and control. This floor-standing single column machine offers simple operation and straightforward structure, making it ideal for quality control in production lines. Designed for testing both non-metallic and metallic materials with loads under 5KN.
ZL-8003A Microcomputer Type Economic Material Testing Machine Documentation
Features imported photoelectric encoder for displacement measurement and an embedded single-chip microcomputer controller with powerful measurement software. Integrated functions include measurement, control, calculation, and storage with automatic stress, elongation, tensile strength, and elasticity modulus calculations.
Testing Capabilities
Comprehensive testing capabilities for tensile, compression, bending, shear, peel, tear, and two-point extension (with extensometer) applications. Suitable for quality control of textiles, rubber, plastics, synthetic leather, tape, adhesives, plastic film, composites, electronics, metals, and various other materials.
Key Features
- Electrostatic spray finish with simple, professional appearance
- LCD digital force display with clear tension/compression indication
- Multiple unit options: N, Kg, Lb, Ton with automatic conversion
- Backlit LCD for low-light environment operation
- Single measurement recording for maximum tension/compression forces
- Automatic or manual zero clearing functionality
- Overload and over-trip protection with automatic shutdown
- Single-column structure offering sophisticated and economical design
Industry Applications
Widely used across multiple industries including wire and cable, hardware, electronic equipment, packaging, printing, medical devices, auto parts, textiles, leather, clothing, footwear, rubber and plastic products. Essential equipment for universities, research laboratories, inspection arbitration, technical supervision departments, and quality management applications.
Technical Specifications
| Maximum Load | 5KN |
| Maximum Stroke | 800mm |
| Pillar Length | 1000mm |
| Test Speed Range | 0.001～500mm/min |
| Dimensions (H×W×D) | 450×550×1400mm |
| Weight | Approximately 150kg |
| Power Requirements | AC 220V |
Standard Configuration
Includes one set of tensile fixtures
